Integrated Sensors and Devices

Rigado’s Cascade Edge Data Network includes the ability to connect easily and securely to a wide range of sensors and devices, and even bundle their cost into the Cascade subscription.

We can connect to devices that meet any of the following criteria:

  • Bluetooth devices using standard protocols (e.g. iBeacon, Eddystone)
  • Bluetooth devices using custom profiles*
  • Wirepas Mesh devices (including Wirepas Positioning Engine)
  • Zigbee and Thread devices *
  • Wi-Fi devices (2.4 & 5 Ghz)
  • Ethernet & TCP/IP devices
  • USB 2.0 devices*
  • All pre-integrated devices & sensor partners listed below
*may require integration services from our Solutions team

The devices listed below represent a subset of our pre-integrated sensors grouped by typical Rigado use-cases.  Please contact us if you have questions about connecting with a specific device.

Occupancy & Presence

Understanding room occupancy and space utilization is proving key to many Smart Workplace and Smart Building applications.

Our solution partners often require real-time data about what’s happening in the buildings the own, operate and occupy.

Typical Rigado solutions that leverage occupancy and presence sensors include:

  • Smart Office / Smart Buildings
  • Space Utilization & Optimization
  • Desk Presence Monitoring
  • Conference / Focus Room Occupancy
Rigado

⤓ RS 40 Occupancy Sensor

  • Small size; peel-and-stick mounting
  • Replaceable AAA batteries
  • Optional Dome Accessory covers sensor lens to narrow detection field
  • Configurable interval and sensitivity
EnOcean

EasyFit EMDCB

  • Self-powered with integrated solar cell and optional backup battery
  • Provides illumination data in addition to presence information
  • Configurable interval and sensitivity

Temperature & Monitoring

The ability to measure and monitor temperature, humidity, air quality and other environmental conditions is a requirement of many Commercial IoT initiatives.

Rigado has partnered and integrated with a wide range of sensor options in this category – from relatively basic and inexpensive options, to CDC-compliant solutions for detailed logging of vaccine conditions.

Rigado solutions that leverage temperature & monitoring sensors include:

  • Cold-chain monitoring & food safety
  • Comfort & air quality for Smart Buildings
  • CDC-compliant vaccine monitoring
  • Supply-chain condition monitoring
Ruuvi

RuuviTag

  • Open-source software & hardware
  • Temperature, movement, air pressure, humidity, and proximity
  • Small form factor, IP67 protected
  • Easy to replace battery
Minew

S1 Sensor

  • Temperature, humidity, movement
  • Built-in flash memory to store up to 200 records
  • IP65 (indoor)
Onset

MX1102A

  • Temperature, Humidity, Dew Point CO2
  • Data logging for up to 84,650 measurements
  • Visual and audible high & low alarm thresholds
  • Self-calibrating NDIR CO2 sensor
  • Configurable sampling interval

Asset Tracking Beacons & Tags

Many of our solutions include location-based services, whether tracking key assets employees ‘by zone’ or providing RTLS positioning to place an asset on a map in real time.

Rigado gateways have been specifically designed for Bluetooth-based asset tracking solutions, and work with a variety of BLE assets and tags.

The types of Rigado solutions that often  include beacons and tags for asset tracking include:

  • Asset Tracking in Warehouses & Hospitals
  • Employee & Key Asset Location in Smart Buildings
  • Tracking people & equipment in construction zones and worksites
Kontakt

Tough Beacon TB15-1

  • UV resistant, impact resistant
  • Built in mounting bracket
  • Only 52x37x27mm
  • IP68
Kontakt

Asset Tag
S18-3

  • Button, LED, accelerometer, temperature
  • Replaceable CR2450 battery
  • Compact 43x43x8mm
  • IP65
Kontakt

ID Card Tag & Accelerometer CT18-3

  • Button, accelerometer, temperature, LED
  • RFID
  • 86x55x4.5 mm
  • IP65

Assorted & General Purpose

The above categories address some of our most common use-cases and device partners – but certainly not all.

The range available IoT sensors and devices is huge, and – because we leverage open standards – Rigado is able to connect our gateways to nearly any device that uses Bluetooth, Wi-Fi, Zigbee, Thread or Wirepas Mesh.

Often, our team is asked to integrate with a set of existing devices (perhaps using an older wireless protocol) – as well as enable connectivity for a new set of devices in development. Our flexible and configurable Edge Connect solution makes this achievable – and affordable.

This section includes some additional devices for which we have pre-integrated solutions, and please contact our solutions team if you have questions about a specific sensor or device.

Minew

i7 Rock Beacon

  • External on/off multifunction button
  • Accelerometer, LED
  • Replaceable CR2477 battery
  • 50 x 15 mm
  • IP65
Minew

C6 Wearable Beacon

  • Accelerometer
  • Replaceable CR2032 coin battery (6mo)
  • Compact 42x31x11mm
  • IP65
Minew

i3 Tough Beacon

  • 5 year battery life
  • 2x AA replaceable batteries
  • 72 x 45 x 22 mm
  • IP66 Waterproof
Minew

Sticker Beacon

Minew Sticker Beacon
  • Ultra-thin 3.3mm, battery replaceable design
  • 50 meter advertising distance
  • 32 x 23 x 3.3 mm
  • Customizable case
Minew

Sticker Beacon Tag

  • Small size, user-friendly and portable
  • 50 meter advertising distance
  • 8 adjustable transmission levels
  • Ø 26 x 5 mm
Minew

Label Beacon Light Sensor

  • Small size, ultrasonic assembling technology
  • 50 meter transmission range, PCB antenna
  • Photoresistor light sensor
  • 42.5 x 23.5 x 5.3 mm
Minew

Beacon Plus

  • Beacon with optional accelerometer
  • 100 meter advertising distance
  • IP67 waterproof case with adhesive mounting
  • Ø 39 x 15.5 mm
Minew

Tag Beacon Accelerometer Sensor

  • Low power consumption 3-axis accelerometer
  • 90 meter advertising distance
  • Customizable waterproof case with keychain hole
  • 36.5 x 23.7 x 5.0 mm
Minew

DearBeacon E9

  • Can include optional NFC tag
  • 100 meter advertising distance
  • IP67 waterproof case with two screw holes for firm mounting
  • Ø 49 x 66 x 17.5 mm
